People who have used membrane switches will come into contact with these two types of membrane switches: planar membrane switches and raised membrane switches; planar membrane switches are relatively smooth, and raised membrane switches have a better feel. For those who do not agree, choose Membrane switches will also be biased, so that when you use it, you will be ready to grasp the switch's function to maximize its effectiveness. At present, the membrane switches sold by the society are mainly raised membrane switches, and its effects are very good, so they are consumed to bring better results.

      Its main advantages are:
       (1) Enhances the decorative effect of the membrane switch appearance.
       (2) The operator's touch is more sensitive.
       (3) Accurately specify the scope of the key body.
       (4) Improve the speed of recognition.
       (5) The raised membrane switch has low cost, simple process and good hand feeling. Therefore occupy the vast majority of the market.

      The good advantage of having a key membrane switch with this sales market is to bring greater value. However, the raised membrane switch also needs to pay attention to certain matters during production and processing:
       (1) need special mold machining, otherwise it can not be formed
       (2) Use excessive force to reduce mechanical life.
       (3) The limit temperature of the raised polyester is 50°C.
       (4) The height of the protrusion should not exceed 1.5 times the thickness of the material.
       (5) Plane bulges should be at least 3mm or 5mm from the edge.
       (6) The raised key of the frame is at least 5 mm from the edge.


       The effect of the raised membrane switch is good, but the premise is that it is based on the production and processing, otherwise the advantage of using the membrane switch convex key will no longer exist, and it will bring even greater drawbacks. National hotline: 0755-27653836
